EVI 10000VA/10000W Rack Mount Online Single Phase UPS-EP-UPS10000P11OR
Key Specifications
- Product Name: EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR
- Brand: EVI
- Model: EP-UPS10000P11OR
- Capacity: 10000VA / 10000W
- UPS Topology: Online Double Conversion
- Phase: Single Phase
- Form Factor: Rack Mount / Tower Convertible
- Input Voltage Range: 110V – 300V AC
- Input Power Factor: 0.99 with PFC
- Output Power Factor: 1.0
- Output Voltage: 200V / 208V / 220V / 230V / 240V AC
- Frequency Range: 40Hz – 70Hz
- Waveform Type: Pure Sine Wave
- Transfer Time: 0ms
- Display: LCD touchscreen status display
- Output Sockets: Multiple IEC C19 and IEC C13 outlets
- Communication Interfaces: USB, RS-232, RS-485, SNMP slot
- Battery Type: External battery bank support
- External Battery Support: Yes
- Backup Time: Expandable depending on battery configuration and load
- Recharge Time: Varies based on battery capacity
- Efficiency: Up to 95%
- Special Features: ECO mode, generator compatibility, Emergency Power Off (EPO), maintenance bypass, intelligent battery management, cold start
- Protection Features: Overload, surge, short circuit, overcharge, deep discharge, and lightning protection
- Warranty: 2 years (1 year on battery)
- Color: Black
- Ideal For: Data centers, enterprise servers, telecom systems, storage arrays, network infrastructure, and mission-critical applications
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Overview
The EVI 10000VA / 10000W Rack Mount Online Single Phase UPS is a high-capacity enterprise power backup solution designed for critical applications that demand continuous uptime and clean, uninterrupted power.
Built with true online double-conversion technology, the UPS continuously converts incoming AC power to DC and back to AC, ensuring connected equipment receives stable pure sine wave output with zero transfer time during power outages and voltage fluctuations.
Its full 10000W output capacity makes it ideal for high-density server environments, data centers, telecom infrastructure, storage systems, and other mission-critical workloads. The rack-mount chassis supports installation in standard 19-inch racks and can also be deployed in tower mode for added flexibility.
The integrated LCD touchscreen display provides real-time monitoring of system status, battery levels, load capacity, input/output voltage, and operating modes for simplified management.
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Price in Kenya
| Product | Price (KSh) |
|---|---|
| EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR | 207,000 |
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Full Specifications
| Specification | Details |
|---|---|
| Brand | EVI |
| Model | EP-UPS10000P11OR |
| Capacity | 10000VA / 10000W |
| Technology | Online Double Conversion |
| Phase | Single Phase |
| Form Factor | Rack Mount / Tower Convertible |
| Input Voltage Range | 110V – 300V AC |
| Input Power Factor | 0.99 with PFC |
| Output Power Factor | 1.0 |
| Output Voltage | 200V / 208V / 220V / 230V / 240V AC |
| Frequency Range | 40Hz – 70Hz |
| Waveform | Pure Sine Wave |
| Transfer Time | 0ms |
| Display | LCD touchscreen |
| Output Connections | IEC C19 and IEC C13 outlets |
| Communication Interfaces | USB, RS-232, RS-485, SNMP slot |
| Battery Configuration | External battery bank support |
| External Battery Support | Yes |
| Runtime | Expandable based on battery configuration |
| Efficiency | Up to 95% |
| Operating Modes | ECO mode, frequency converter mode |
| EPO Support | Yes |
| Maintenance Bypass | Yes |
| Generator Compatibility | Yes |
| Protection | Overload, surge, short circuit, overcharge, deep discharge, lightning protection |
| Warranty | 2 years (1 year on battery) |
| Color | Black |
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Design & Build Quality
The UPS features a heavy-duty rack-mount chassis engineered for demanding enterprise deployments.
Key design highlights include:
- Rack-mount and tower-convertible installation
- Durable metal enclosure for continuous operation
- LCD touchscreen for real-time monitoring
- Front-access controls and status indicators
- Intelligent cooling system with variable-speed fans
- Support for external battery modules
- Standard 19-inch rack compatibility
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Performance
Designed for mission-critical environments, the UPS delivers continuous clean power and advanced protection for sensitive equipment.
Key performance features include:
- True online double-conversion technology
- Zero transfer time during power interruptions
- Pure sine wave output for sensitive equipment
- Full 10000W usable output capacity
- Wide input voltage range minimizes battery usage
- Intelligent battery management extends battery lifespan
- Generator compatibility for hybrid backup systems
- Maintenance bypass enables servicing without downtime
- ECO mode improves energy efficiency during stable power conditions
Runtime depends on the connected load and external battery configuration, allowing organizations to scale backup duration according to their requirements.
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Connectivity and Compatibility
- Input Connection: Hardwired terminal block
- Output Connections: IEC C19 and IEC C13 outlets
- Communication Ports: USB, RS-232, RS-485
- Network Management: Optional SNMP card support
- Emergency Power Off (EPO): Yes
- Output Voltage: User-selectable 200V / 208V / 220V / 230V / 240V AC
Compatible Devices:
- Rack servers
- Blade servers
- Network switches
- Storage arrays and NAS systems
- Firewalls and security appliances
- Telecom equipment
- CCTV infrastructure
- Data center equipment
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Applications
- Data centers
- Server rooms
- Network cabinets
- Enterprise IT environments
- Telecommunications systems
- Financial institutions
- Healthcare facilities
- Industrial control systems
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Pros & Cons
| Pros |
|
|---|---|
| Full 10000W usable output capacity | Higher cost than line interactive UPS models |
| Pure sine wave output | Requires professional installation |
| Zero transfer time | Large and heavy unit |
| Maintenance bypass support | External battery bank may require additional space |
| SNMP support for remote monitoring | Requires dedicated rack space |
Frequently Asked Questions (FAQs)
What is the price of the EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR in Kenya?
The EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR is priced at KSh 207,000 in Kenya.
Does this UPS provide pure sine wave output?
Yes. The UPS delivers a pure sine wave output, making it suitable for sensitive equipment such as servers, storage systems, networking hardware, and telecom infrastructure.
Can this UPS be remotely monitored?
Yes. The UPS supports remote management through USB, RS-232, RS-485, and an optional SNMP network card.
Is this UPS compatible with generators?
Yes. The UPS supports generator operation, making it suitable for installations with standby generator systems.
Is this UPS suitable for data centers?
Yes. With a 10000W output capacity, online double-conversion technology, and zero transfer time, it is designed for data centers, server rooms, and other mission-critical environments.
EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR Conclusion
The EVI 10000VA / 10000W Rack Mount Online Single Phase UPS - EP-UPS10000P11OR is an enterprise-grade backup solution built to protect critical infrastructure from power interruptions, voltage fluctuations, and electrical disturbances.
At KSh 207,000, it delivers outstanding value with features such as online double-conversion technology, pure sine wave output, maintenance bypass, generator compatibility, remote management capabilities, and a full 10000W output capacity, making it an ideal choice for data centers, telecom installations, and large-scale business environments.
