EVI 6000VA/5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT
Key Specifications
- Product Name: EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT
- Brand: EVI
- Model: EP-UPS6000Y11OT
- Capacity: 6000VA / 5400W
- UPS Topology: Online Double Conversion with DSP Control
- Phase: Single Phase
- Form Factor: Tower
- Input Voltage Range: 120V – 276V AC
- Input Frequency Range: 45–55Hz (50Hz) / 54–66Hz (60Hz)
- Input Current Harmonic Distortion: Less than 3%
- Output Power Factor: 0.9
- Output Voltage: 220V / 230V / 240V AC
- Waveform Type: Pure Sine Wave
- Transfer Time: 0ms
- Display: Rotating LCD display
- Communication Interfaces: USB, RS-232
- Optional Communication Cards: SNMP, Parallel, Relay cards
- Battery Type: Sealed lead-acid batteries with optional lithium battery support
- Charging Current: Selectable 1A / 2A
- Backup Time: Up to 15–30 minutes (load dependent)
- Efficiency: Up to 95% in ECO mode
- Special Features: ECO mode, cold start, self-test, Emergency Power Off (EPO), low-priority load shutdown, generator compatibility
- Protection Features: Overload, surge, short circuit, overcharge, deep discharge, and lightning protection
- Warranty: 2 years (1 year on battery)
- Color: Black
- Ideal For: Data centers, servers, telecom systems, medical equipment, industrial automation, and mission-critical applications
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Overview
The EVI 6000VA / 5400W Tower Online Single Phase UPS is a high-capacity enterprise power protection solution designed for environments where uninterrupted operation is critical.
Built with true online double-conversion technology and advanced DSP control, the UPS continuously converts incoming AC power to DC and back to AC, delivering clean pure sine wave output with zero transfer time during outages and voltage fluctuations.
Its robust 5400W output capacity makes it suitable for protecting servers, networking equipment, telecom infrastructure, industrial control systems, and medical devices. The tower form factor enables easy deployment in server rooms and equipment areas without requiring rack space.
The integrated rotating LCD display provides real-time information on system status, load levels, battery condition, and input/output parameters for simplified monitoring and management.
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Price in Kenya
| Product | Price (KSh) |
|---|---|
| EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT | 137,000 |
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Full Specifications
| Specification | Details |
|---|---|
| Brand | EVI |
| Model | EP-UPS6000Y11OT |
| Capacity | 6000VA / 5400W |
| Technology | Online Double Conversion with DSP Control |
| Phase | Single Phase |
| Form Factor | Tower |
| Input Voltage Range | 120V – 276V AC |
| Input Frequency Range | 45–55Hz (50Hz) / 54–66Hz (60Hz) |
| Input Harmonic Distortion | <3% |
| Output Power Factor | 0.9 |
| Output Voltage | 220V / 230V / 240V AC |
| Waveform | Pure Sine Wave |
| Transfer Time | 0ms |
| Display | Rotating LCD |
| Communication Interfaces | USB, RS-232 |
| Optional Cards | SNMP, Parallel, Relay |
| Battery Type | Sealed lead-acid with optional lithium support |
| Charging Current | Selectable 1A / 2A |
| Backup Time | Up to 15–30 minutes |
| Efficiency | Up to 95% in ECO mode |
| Generator Compatibility | Yes |
| EPO Support | Yes |
| Protection | Overload, surge, short circuit, overcharge, deep discharge, lightning protection |
| Warranty | 2 years (1 year on battery) |
| Color | Black |
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Design & Build Quality
The UPS features a robust tower design engineered for continuous operation in demanding business environments.
Key design highlights include:
- Heavy-duty tower chassis
- Rotating LCD display for easy monitoring
- Durable metal enclosure
- Front-access controls and status indicators
- Terminal block connections for flexible installation
- Intelligent cooling system with variable-speed fans
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Performance
Designed for mission-critical applications, the UPS delivers continuous clean power and advanced protection for sensitive equipment.
Key performance features include:
- True online double-conversion technology
- Zero transfer time during power interruptions
- Pure sine wave output for sensitive electronics
- Wide input voltage range minimizes battery usage
- High 5400W usable output capacity
- Input harmonic distortion below 3%
- Generator compatibility for hybrid backup systems
- Intelligent battery management extends battery lifespan
- ECO mode improves energy efficiency during stable power conditions
Runtime varies according to the connected load, with typical backup duration ranging from 15 to 30 minutes under standard operating conditions.
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Connectivity and Compatibility
- Input Connection: Terminal block
- Output Connection: Terminal block
- Communication Ports: USB and RS-232
- Optional Network Management: SNMP card support
- Emergency Power Off (EPO): Yes
- Output Voltage: User-selectable 220V / 230V / 240V AC
Compatible Devices:
- Enterprise servers
- Network switches
- Storage arrays
- Telecom systems
- Medical equipment
- Industrial controllers
- CCTV infrastructure
- Data center equipment
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Applications
- Data centers
- Server rooms
- Telecommunications systems
- Healthcare facilities
- Industrial automation
- Financial institutions
- Security and surveillance systems
- Mission-critical infrastructure
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Pros & Cons
| Pros | Cons |
|---|---|
| Pure sine wave output | Higher cost than line interactive UPS models |
| Zero transfer time | Requires professional installation |
| High 5400W output capacity | Large and heavy unit |
| Generator compatibility | Lead-acid batteries require periodic replacement |
| Optional SNMP support for remote monitoring | Requires dedicated installation space |
Frequently Asked Questions (FAQs)
What is the price of the EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT in Kenya?
The EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT is priced at KSh 137,000 in Kenya.
Does this UPS provide pure sine wave output?
Yes. The UPS delivers a pure sine wave output, making it suitable for sensitive equipment such as servers, medical devices, storage systems, and networking hardware.
Can this UPS be remotely monitored?
Yes. The UPS includes USB and RS-232 interfaces and supports optional SNMP, relay, and parallel cards for advanced monitoring and management.
Is this UPS compatible with generators?
Yes. The UPS supports generator input and is designed to operate reliably in environments with unstable power conditions.
Can this UPS start without mains power?
Yes. The UPS supports cold start capability, allowing it to power connected equipment directly from battery power during emergencies.
EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT Conclusion
The EVI 6000VA / 5400W Tower Online Single Phase UPS - EP-UPS6000Y11OT is an enterprise-grade backup solution designed to deliver maximum uptime and comprehensive power protection.
At KSh 137,000, it offers excellent value with features such as online double-conversion technology, pure sine wave output, generator compatibility, optional remote management capabilities, and a robust 5400W output capacity, making it an ideal choice for mission-critical business environments.
