Fanvil i507W Android Indoor Station

Key Features of Fanvil i507W Android Indoor Station

• Display – 10.1-Inch IPS Color Capacitive Touchscreen

• Resolution – 1280 × 800 Pixels

• Operating System – Android 9.0

• Wi-Fi – Dual-Band 2.4GHz & 5GHz

• Ethernet – 10/100 Mbps RJ45

• PoE – IEEE 802.3af

• Speaker – 2W

• Audio – Full-Duplex Hands-Free

• Audio Processing – Acoustic Echo Cancellation

• Video – H.264 / H.265

• Video Resolution – Up to 1080p

• Alarm Inputs – 8

• IP Camera Monitoring – Supported

• Remote Door Unlocking – Supported

• SIP – SIP 2.0

• Installation – Wall Mount

Overview of Fanvil i507W Android Indoor Station

The Fanvil i507W Android Indoor Station is a 10.1-inch touchscreen SIP video intercom and access-control device designed for residential communities, villas, office buildings, hotels and smart-building environments. It runs Android 9.0 and provides a large color touchscreen for visitor communication, video monitoring and access-control functions. The i507W supports dual-band Wi-Fi, Ethernet and IEEE 802.3af PoE, allowing flexible network installation. It also provides two-way hands-free communication, remote door unlocking, IP camera monitoring and multiple alarm interfaces for connecting security sensors.

Fanvil i507W Android Indoor Station Price in Kenya

Specifications of Fanvil i507W Android Indoor Station

Performance Features of Fanvil i507W Android Indoor Station

• Large 10.1-Inch Touchscreen: The i507W provides a spacious 10.1-inch color capacitive touchscreen with a 1280 × 800 resolution, giving users a convenient interface for video intercom calls, visitor identification, camera monitoring and access-control functions.

• HD Video Intercom: The station supports SIP-based video communication with compatible door stations and indoor devices. H.264 and H.265 video decoding support allows it to handle compatible high-definition video sources, with support for video resolutions up to 1080p.

• Hands-Free HD Audio: A built-in 2W speaker and Acoustic Echo Cancellation support full-duplex hands-free conversations, providing clear two-way communication between occupants and visitors without requiring a traditional telephone handset.

• Android 9.0 Platform: Android 9.0 provides a familiar interface while allowing compatible third-party applications and customized industry applications to be integrated into the indoor station.

Connectivity and Access-Control Features of Fanvil i507W Android Indoor Station

• Dual-Band Wi-Fi: The i507W supports 2.4GHz and 5GHz Wi-Fi, providing flexible wireless connectivity for installations where Ethernet cabling may be inconvenient.

• PoE Networking: IEEE 802.3af PoE allows power and network connectivity to be delivered through a compatible Ethernet connection, helping simplify installation.

• Remote Door Unlocking: Users can remotely unlock compatible entrances after communicating with visitors, making the i507W suitable for controlled-access residential and commercial properties.

• IP Camera Monitoring: The station can monitor compatible third-party IP cameras and access-control cameras, allowing users to view security feeds directly from the indoor touchscreen.

Security and Integration Features of Fanvil i507W Android Indoor Station

• Eight Alarm Inputs: Eight alarm input interfaces allow compatible sensors and security devices to be connected to the indoor station for broader security monitoring.

• Multiple Integration Interfaces: The i507W provides expansion interfaces designed to connect security devices and sensors, allowing it to form part of a wider building security and access-control system.

• SIP Integration: SIP 2.0 support over UDP, TCP and TLS allows the i507W to integrate with compatible SIP servers, IP PBX systems, door phones and video intercom systems.

• Third-Party Application Support: The Android platform allows compatible applications to extend the functionality of the indoor station for specialized building-management, security and property-management applications.

Installation Features of Fanvil i507W Android Indoor Station

• Wall-Mounted Design: The i507W is designed for fixed indoor wall installation, making it suitable for apartments, villas, offices, hotels and other buildings.

• Flexible Power: The station can be powered through compatible PoE infrastructure or an external power source, giving installers flexibility during deployment.

• Indoor Security Terminal: Its combination of touchscreen control, video communication, camera monitoring, door unlocking and alarm connectivity allows multiple security functions to be managed from one indoor station.

Applications of Fanvil i507W Android Indoor Station

• Residential apartments

• Gated communities

• Villas

• Office buildings

• Hotels

• Serviced apartments

• Commercial buildings

• Smart buildings

• Visitor-management systems

• Video intercom systems

• Access-control systems

• Building security installations

Pros and Cons of Fanvil i507W Android Indoor Station

FAQs About Fanvil i507W Android Indoor Station

What is the Fanvil i507W used for?

The Fanvil i507W is an Android-based indoor video intercom and access-control station used for visitor communication, video monitoring, remote door unlocking and security integration.

What size screen does the Fanvil i507W have?

The i507W features a 10.1-inch color capacitive touchscreen with a 1280 × 800 pixel resolution.

Does the Fanvil i507W support Wi-Fi?

Yes. The i507W supports dual-band 2.4GHz and 5GHz Wi-Fi.

Does the Fanvil i507W support PoE?

Yes. It supports IEEE 802.3af PoE, allowing power and network connectivity through a compatible Ethernet connection.

Can the Fanvil i507W unlock doors?

Yes. The i507W supports remote door unlocking when integrated with compatible access-control equipment.

How many alarm inputs does the Fanvil i507W have?

The i507W provides 8 alarm input interfaces for compatible security sensors and devices.

Does the Fanvil i507W support IP cameras?

Yes. It supports monitoring compatible third-party IP cameras and access-control cameras.

What operating system does the Fanvil i507W use?

The i507W runs Android 9.0 and supports compatible third-party applications.

Conclusion

The Fanvil i507W Android Indoor Station combines a large 10.1-inch touchscreen with SIP video intercom, dual-band Wi-Fi, PoE, remote door unlocking, IP camera monitoring and eight alarm inputs. Its Android platform and multiple interfaces make it a flexible indoor security and communication terminal for residential communities, villas, hotels, offices and smart-building installations.
