Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Key Features
- 5 GHz airMAX wireless technology
- 23 dBi integrated directional antenna
- Up to 100 Mbps real outdoor throughput
- 1 × 10/100 Ethernet port
- Up to 25 dBm output power
- Passive PoE power
- 24V 0.2A PoE adapter included
- 64MB memory
- Atheros MIPS processor
- InnerFeed antenna technology
- airMAX TDMA protocol
- Pole mounting kit included
- Lightweight 750 g design
- UV-stabilized outdoor construction
- Up to 200 km/h wind survivability
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Overview
The Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) is a lightweight outdoor wireless broadband device designed for long-distance wireless bridging. Operating in the 5 GHz frequency range, it combines a high-gain 23 dBi directional antenna with Ubiquiti airMAX technology to provide reliable connectivity for Point-to-Point and other outdoor wireless networking applications.
The LiteBeam M5 uses InnerFeed technology, which integrates the radio system into the antenna feed for a compact and efficient design. Its passive PoE operation, pole mounting system, and rugged outdoor construction make it suitable for wireless ISPs, rural broadband, remote locations, surveillance backhaul, and enterprise wireless bridges.
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Price Table
| Product | Price (KES) |
|---|---|
| Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) | KSh 7,500 – 10,000 (Approx.) |
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Key Specs
| Specification | Details |
|---|---|
| Model | LBE-M5-23 |
| Wireless Technology | airMAX 802.11n |
| Frequency Band | 5 GHz |
| Operating Frequency | 5150–5875 MHz Worldwide |
| Antenna Gain | 23 dBi |
| Maximum Output Power | 25 dBm |
| Ethernet Port | 1 × 10/100 Ethernet |
| Memory | 64 MB |
| Processor | Atheros MIPS 74Kc |
| Power Method | Passive PoE |
| Power Supply | 24V 0.2A PoE Adapter |
| Maximum Power Consumption | 4W |
| Dimensions | 362 × 267 × 184 mm |
| Weight | 750 g |
| Mounting | Pole Mount |
| Operating Temperature | -40°C to 70°C |
| Operating Humidity | 5–95% Noncondensing |
| Wind Survivability | Up to 200 km/h |
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Performance
- 23 dBi antenna gain supports long-distance wireless links.
- 5 GHz operation provides focused outdoor connectivity.
- Up to 25 dBm output power improves link performance.
- airMAX TDMA technology improves wireless efficiency.
- InnerFeed technology integrates the radio and antenna feed.
- Narrow directional coverage helps reduce unwanted interference.
- Suitable for Point-to-Point wireless bridges.
- Reliable performance for ISP infrastructure.
- Efficient 4W power consumption.
- Designed for continuous outdoor operation.
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Smart Features
- airMAX TDMA technology
- InnerFeed antenna technology
- airOS management
- 23 dBi directional antenna
- Passive PoE operation
- Remote device management
- Wireless link monitoring
- Point-to-Point support
- Outdoor wireless optimization
- High-gain directional connectivity
- Professional wireless deployment
- Efficient power management
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Design & Build
- Lightweight 750 g construction
- Compact outdoor-ready design
- UV-stabilized enclosure
- Integrated directional antenna
- Pole mounting kit included
- Weather-resistant outdoor construction
- InnerFeed integrated radio design
- Efficient passive cooling
- Professional outdoor appearance
- Designed for long-term outdoor deployment
- Wind survivability up to 200 km/h
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Connectivity
- 1 × 10/100 Ethernet port
- 5 GHz wireless connectivity
- 24V Passive PoE
- Integrated 23 dBi antenna
- Point-to-Point wireless connectivity
- Long-distance wireless bridging
- Outdoor broadband connectivity
- Enterprise LAN integration
- ISP wireless infrastructure
- Remote site networking
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Use Cases
- Wireless ISP deployments
- Point-to-Point wireless bridges
- Rural broadband connectivity
- Remote site networking
- CCTV surveillance backhaul
- Enterprise wireless links
- Building-to-building connectivity
- Outdoor broadband networks
- Industrial wireless networking
- Long-distance wireless infrastructure
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Pros & Cons
| Pros | Cons |
|---|---|
| High 23 dBi antenna gain | 10/100 Ethernet only |
| Long-distance 5 GHz connectivity | Older airMAX platform |
| Lightweight and compact | No Gigabit Ethernet |
| Low 4W power consumption | 5 GHz operation only |
| Passive PoE adapter included | Professional alignment recommended |
| Strong outdoor durability | — |
| Easy pole mounting | — |
| Suitable for ISP deployments | — |
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) FAQs
Q1: What is the antenna gain of the LiteBeam M5?
The LBE-M5-23 features a 23 dBi directional antenna designed for long-distance wireless connectivity.
Q2: What frequency does the LBE-M5-23 use?
It operates in the 5 GHz band, with a worldwide operating range of approximately 5150–5875 MHz.
Q3: How many Ethernet ports does it have?
It has 1 × 10/100 Ethernet port for network connectivity and Passive PoE power.
Q4: Does the LiteBeam M5 include a PoE adapter?
Yes. The package includes a 24V 0.2A Passive PoE adapter.
Q5: Is the LiteBeam M5 suitable for long-distance wireless links?
Yes. Its 23 dBi directional antenna, 5 GHz operation, and airMAX technology make it well suited to long-distance Point-to-Point wireless bridging and ISP deployments.
Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) Conclusion
The Ubiquiti LiteBeam M5 23dBi 5GHz Wireless Broadband CPE (LBE-M5-23) is a lightweight and cost-effective outdoor wireless solution combining 23 dBi antenna gain, 5 GHz airMAX technology, Passive PoE, and InnerFeed technology. Its compact construction, directional performance, and long-range capabilities make it an excellent choice for wireless ISPs, Point-to-Point bridges, rural broadband, and outdoor networking deployments in Kenya.
