MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD
- 5GHz 802.11ac wireless connectivity provides high-speed outdoor wireless networking.
- 16dBi integrated antenna provides focused wireless transmission and reception.
- Gigabit Ethernet port provides a high-speed wired network connection.
- Up to 866.7Mbps wireless data rate provides fast wireless connectivity under supported conditions.
- 2×2 MIMO technology improves wireless throughput and link performance.
- 28dBm maximum transmit power provides strong wireless transmission capability.
- RouterOS provides advanced wireless, routing and network-management features.
- Level 4 RouterOS license supports CPE and wireless network deployments.
- Outdoor-rated enclosure protects the device in demanding outdoor environments.
- IP54 protection provides resistance against dust and water exposure.
- Passive PoE input allows the device to receive power and data through Ethernet.
- Passive cooling provides quiet operation without an active cooling fan.
- Compact design makes the CPE suitable for poles, masts and wall installations.
- Integrated directional antenna helps create focused point-to-point wireless links.
- Low-power operation supports practical outdoor deployments.
- Price in Kenya: KSh 10,500.
Description
The MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD is a compact outdoor wireless CPE designed for point-to-point links, wireless backbones, broadband customer premises equipment and long-range 5GHz network deployments. It combines a high-gain integrated antenna with 802.11ac wireless technology and a Gigabit Ethernet interface.
The SXTsq 5 ac operates on the 5GHz wireless band and supports 802.11ac technology, providing high-speed wireless connectivity for compatible network infrastructure. Its 16dBi directional antenna focuses the wireless signal, making the device suitable for establishing dedicated wireless links between two locations.
The device uses 2×2 MIMO technology and supports wireless data rates of up to 866.7Mbps under appropriate conditions. Actual throughput depends on factors such as distance, interference, channel configuration, antenna alignment and environmental conditions.
The SXTsq 5 ac features a Gigabit Ethernet port for connecting the wireless unit to a router, switch, computer or other network equipment. It can receive power through passive PoE, simplifying outdoor installation by allowing power and data to travel through the same Ethernet cable.
The device runs MikroTik RouterOS, providing advanced configuration options for wireless links, routing, firewalling, network management and other supported networking functions. Its compact outdoor enclosure and mounting options make it practical for installations on poles, masts and building structures.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Price in Kenya
| ProductPrice | |
|---|---|
| MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD | KSh 10,500 |
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Key Specifications
| SpecificationDetails | |
|---|---|
| Product Type | Outdoor 5GHz Wireless CPE |
| Brand | MikroTik |
| Model | SXTsq 5 ac |
| Product Code | RBSXTSQG-5acD |
| Wireless Standard | 802.11a/n/ac |
| Wireless Frequency | 5GHz |
| Antenna Gain | 16dBi |
| Antenna Type | Integrated Directional Antenna |
| MIMO | 2×2 MIMO |
| Maximum Wireless Data Rate | 866.7Mbps |
| Ethernet Port | 1 × Gigabit Ethernet |
| Wireless Chipset | Qualcomm QCA9887 |
| CPU | Qualcomm Atheros QCA9531 |
| CPU Cores | 1 |
| CPU Frequency | 650MHz |
| RAM | 64MB |
| Storage | 16MB Flash |
| Operating System | RouterOS |
| RouterOS License | Level 4 |
| Maximum Transmit Power | 28dBm |
| PoE Input | Passive PoE |
| Cooling | Passive Cooling |
| Weather Protection | IP54 |
| Installation | Pole / Mast / Wall Mount |
| Color | White |
| Price | KSh 10,500 |
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Design & Build
- Compact outdoor enclosure provides a practical form factor for external installations.
- 16dBi integrated directional antenna focuses wireless signals toward the target location.
- Outdoor-rated construction makes the device suitable for external wireless deployments.
- IP54 protection helps protect against dust and water exposure.
- Pole and mast mounting provides flexibility for point-to-point installations.
- Wall-mounting capability provides an alternative installation option.
- Lightweight construction simplifies installation on poles and building structures.
- Integrated antenna design eliminates the need for a separate external antenna.
- Passive cooling provides quiet operation without an active fan.
- Compact profile helps reduce wind loading compared with larger outdoor antenna systems.
- Professional outdoor construction supports wireless backbone and CPE deployments.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Connectivity
- 5GHz wireless connectivity provides high-speed outdoor wireless communication.
- 802.11ac support enables high-speed wireless networking with compatible devices.
- 16dBi directional antenna provides focused wireless coverage.
- Gigabit Ethernet port provides a wired connection to local network equipment.
- Passive PoE input allows power and data to be delivered through Ethernet.
- Point-to-point connectivity allows two compatible units to establish a dedicated wireless link.
- Wireless backbone connectivity allows locations to be connected without laying physical cable.
- Router connectivity allows the SXTsq to connect directly to compatible network routers.
- Switch connectivity allows integration with wired network infrastructure.
- Network bridge deployments allow wireless links to extend an existing LAN.
- CPE connectivity provides wireless broadband access at remote locations.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Performance
- 866.7Mbps maximum wireless data rate provides high wireless capacity under supported conditions.
- 2×2 MIMO improves wireless performance by using multiple spatial streams.
- 802.11ac technology provides faster wireless networking than older 802.11a/n-only deployments.
- 16dBi antenna gain provides focused directional transmission and reception.
- 28dBm maximum transmit power supports long-range outdoor wireless links.
- Gigabit Ethernet interface prevents the wired connection from becoming an immediate Fast Ethernet bottleneck.
- 5GHz operation provides access to a high-speed wireless band suitable for outdoor links.
- Directional antenna design improves link efficiency when correctly aligned.
- RouterOS optimization provides extensive configuration options for wireless networking.
- Outdoor wireless architecture makes the device suitable for dedicated wireless backbone connections.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Network Management
- RouterOS provides advanced wireless and network-management functionality.
- Wireless mode configuration allows the device to be configured for supported CPE and backbone applications.
- Point-to-point configuration supports dedicated wireless links between locations.
- Bridge configuration allows wireless connectivity to be integrated with wired LANs.
- Routing functionality allows supported IP routing configurations.
- Firewall functionality provides tools for controlling network traffic.
- Bandwidth management allows administrators to control traffic according to configured policies.
- Network monitoring provides visibility into wireless and Ethernet interface activity.
- Wireless signal monitoring assists with link alignment and performance management.
- RouterOS configuration provides detailed control for professional network administrators.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Power & Installation
- Passive PoE input allows power to be delivered through Ethernet.
- PoE-powered outdoor deployment simplifies installation where electrical power is not directly available at the mounting point.
- Gigabit Ethernet connection carries both network traffic and power when used with compatible passive PoE equipment.
- Pole mounting supports outdoor point-to-point wireless installations.
- Mast installation provides elevated positioning for improved line-of-sight.
- Wall mounting provides flexibility for building-based deployments.
- Compact enclosure simplifies outdoor installation.
- Passive cooling eliminates the need for an active cooling fan.
- IP54 protection supports outdoor installation in suitable environmental conditions.
- Directional alignment is important for achieving optimal point-to-point wireless performance.
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Ideal Use Cases
- Point-to-point wireless links
- Wireless network backbones
- Outdoor CPE deployments
- Internet service provider networks
- Wireless broadband networks
- Building-to-building connectivity
- Remote office connectivity
- Rural wireless internet
- Long-range 5GHz wireless links
- Network extension between buildings
- Campus network connections
- Business wireless backbones
- Remote location networking
- Temporary network links
- Outdoor network infrastructure
- Wireless LAN bridging
- CPE installations
- MikroTik wireless networks
- Point-to-point LAN extension
- Professional outdoor networking
MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD Pros and Cons
| ProsCons | |
|---|---|
| 16dBi integrated directional antenna | Requires accurate alignment for point-to-point links |
| 5GHz 802.11ac support | Performance can be affected by interference and obstacles |
| Up to 866.7Mbps wireless rate | 5GHz generally has less obstacle penetration than lower-frequency bands |
| Gigabit Ethernet port | Only one Ethernet port |
| 2×2 MIMO | No built-in multi-band Wi-Fi |
| RouterOS support | RouterOS can have a learning curve for new users |
| Passive PoE support | Power accessories must be compatible with the device |
| Compact outdoor design | IP54 protection does not make it suitable for every extreme outdoor environment |
| Pole and wall mounting | Requires suitable mounting location and line-of-sight |
| Affordable price | Actual wireless throughput depends on environmental and configuration factors |
FAQs
1. How much is the MikroTik SXTsq 5 ac in Kenya?
The listed price for the MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD is KSh 10,500.
2. What frequency does the MikroTik SXTsq 5 ac use?
The SXTsq 5 ac operates on the 5GHz wireless band and supports 802.11a/n/ac wireless standards.
3. What is the antenna gain of the MikroTik SXTsq 5 ac?
The device features an integrated 16dBi directional antenna, designed to focus wireless signals for outdoor links.
4. Does the MikroTik SXTsq 5 ac support 802.11ac?
Yes. The SXTsq 5 ac supports 802.11ac, providing high-speed wireless connectivity with compatible 5GHz equipment.
5. What wireless speed does the MikroTik SXTsq 5 ac support?
The SXTsq 5 ac supports a maximum wireless data rate of up to 866.7Mbps under supported conditions. Actual throughput depends on link distance, interference, channel configuration, alignment and environmental factors.
6. Does the MikroTik SXTsq 5 ac have a Gigabit Ethernet port?
Yes. It has one Gigabit Ethernet port for connecting the CPE to routers, switches, computers and other network equipment.
7. Can the MikroTik SXTsq 5 ac be used for point-to-point connections?
Yes. Two compatible SXTsq 5 ac units can be configured for point-to-point wireless connectivity, making them suitable for connecting buildings or extending networks across suitable distances.
8. Does the MikroTik SXTsq 5 ac support PoE?
Yes. The device supports passive PoE input, allowing power and network data to be carried through the Ethernet connection.
9. Is the MikroTik SXTsq 5 ac suitable for outdoor installation?
Yes. The SXTsq 5 ac is designed for outdoor wireless deployments and features an IP54-rated enclosure. It should still be installed according to the manufacturer's environmental and mounting requirements.
10. Is the MikroTik SXTsq 5 ac worth buying at KSh 10,500?
At KSh 10,500, the SXTsq 5 ac is a strong option for users who need a 16dBi directional antenna, 5GHz 802.11ac wireless connectivity, Gigabit Ethernet, passive PoE, RouterOS and a compact outdoor enclosure for point-to-point and wireless backbone deployments.
Conclusion
The MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD is a compact outdoor wireless networking solution designed for point-to-point links, wireless backbones, broadband CPE deployments, building-to-building connections and professional outdoor network infrastructure. With 5GHz 802.11ac support, a 16dBi integrated directional antenna, 2×2 MIMO, up to 866.7Mbps wireless data rates, Gigabit Ethernet, passive PoE and RouterOS, it provides a strong combination of wireless performance and network-management flexibility.
At KSh 10,500, the MikroTik SXTsq 5 ac 16dBi 5GHz Integrated CPE Backbone RBSXTSQG-5acD is a suitable choice for Internet service providers, network administrators, IT professionals, businesses, rural broadband deployments, wireless installers and organizations looking to establish reliable 5GHz point-to-point or wireless backbone connections.
