Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Key Features

• Suprema BioEntry W2 BEW2-ODPB

• Outdoor IP access-control reader

• Dual-frequency RFID support

• 125kHz EM RFID

• 13.56MHz MIFARE, MIFARE Plus, DESFire and FeliCa

• Up to 500,000 users

• Up to 500,000 card credentials

• 1,000,000 text-log capacity

• 1.2GHz quad-core CPU

• 2GB Flash + 256MB RAM

• 10/100 Mbps Ethernet

• RS-485 with OSDP V2

• Wiegand input/output

• 2 input channels and 1 relay

• IEEE 802.3af PoE support

• IP67 protection

• IK09 impact resistance

• Multi-colour LED and multi-tone buzzer

• Compact outdoor design

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Overview

The Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader is a rugged outdoor access-control device designed for environments requiring reliable RFID-based authentication. It supports 125kHz EM and 13.56MHz RFID technologies, including MIFARE, MIFARE Plus, DESFire and FeliCa.

The BEW2-ODPB is built around a 1.2GHz quad-core CPU, with 2GB Flash and 256MB RAM. Its large capacity supports up to 500,000 users and 500,000 card credentials, while up to 1,000,000 text logs can be stored for access-event records.

For outdoor installations, the reader features IP67 ingress protection and IK09 impact protection, helping it withstand dust, water exposure and physical impact. Suprema describes the BioEntry W2 as suitable for demanding outdoor access-control environments.

The reader provides several integration options, including 10/100 Mbps Ethernet, RS-485 with OSDP V2, Wiegand, two inputs, one relay and IEEE 802.3af PoE. This allows it to be integrated into networked access-control systems and compatible controllers.

Price in Kenya: KSh 80,000.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Price

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Specifications

*Mobile credential availability should be verified against the exact hardware revision; Suprema's current documentation lists NFC/BLE for the ODPB configuration.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader RFID & Access Features

• Dual-frequency RFID support allows the reader to work with both 125kHz EM and 13.56MHz credentials, providing flexibility for different access-card environments.

• MIFARE and DESFire compatibility provides support for widely used 13.56MHz smart-card technologies.

• FeliCa support expands credential compatibility for supported deployments.

• Large credential capacity supports up to 500,000 users and 500,000 card credentials, making the device suitable for large access-control installations.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Connectivity & Integration Features

• 10/100 Mbps Ethernet connectivity allows the reader to communicate with networked access-control systems over standard Ethernet infrastructure.

• RS-485 with OSDP V2 provides standardized communication with compatible access-control controllers.

• Wiegand input/output provides an additional integration option for compatible access-control equipment.

• Two inputs and one relay allow connection to suitable external access-control devices and door hardware.

• IEEE 802.3af PoE support can simplify installation by allowing compatible Ethernet infrastructure to provide power to the reader.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Outdoor Protection Features

• IP67 protection helps protect the reader against dust and water, making it suitable for outdoor access points.

• IK09 impact protection provides resistance against physical impact in demanding installation environments.

• -20°C to 50°C operating temperature supports deployment across a broad range of environmental conditions.

• Compact outdoor enclosure makes the reader suitable for doors, gates and other controlled entry points.

• Tamper support provides an additional security measure for installations where unauthorized interference needs to be detected.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Applications

• Office Access Control

• Commercial Building Access

• Outdoor Gate Access

• Warehouse Access Control

• Factory Entry Systems

• School and Institutional Security

• Restricted Area Access

• Employee Access Management

• Loading Dock Access

• Networked Access Control Systems

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Pros and Cons

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader FAQs

What is the Suprema BEW2-ODPB used for?

It is an outdoor RFID access-control reader designed for controlled-entry systems.

Does the BEW2-ODPB have a fingerprint scanner?

No. Suprema's current specifications list no biometric fingerprint functionality for the BEW2-ODPB. The fingerprint-equipped variant is the BEW2-OHPB.

What RFID cards does the BEW2-ODPB support?

It supports 125kHz EM and 13.56MHz MIFARE, MIFARE Plus, DESFire and FeliCa cards.

Is the BEW2-ODPB suitable for outdoor use?

Yes. It has IP67 ingress protection and IK09 impact protection, making it suitable for demanding outdoor installations.

Does the BEW2-ODPB support PoE?

Yes. It supports IEEE 802.3af PoE.

What connectivity does the BEW2-ODPB provide?

It supports 10/100 Mbps Ethernet, RS-485 with OSDP V2 and Wiegand, along with two inputs and one relay.

What is the Suprema BEW2-ODPB price in Kenya?

The listed price is KSh 80,000.

Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader Conclusion

The Suprema BEW2-ODPB BioEntry W2 Dual RFID Reader is a rugged outdoor access-control reader designed around dual-frequency RFID authentication, large credential capacity, Ethernet, OSDP V2, Wiegand and PoE connectivity. Its IP67 and IK09 protection make it suitable for outdoor doors, gates, warehouses, offices and other demanding access-control environments.
