Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Key Features

• Ethernet to Ethernet surge protection
• 10kA+ discharge current
• Two passive surge-protected RJ45 ports
• Supports Gigabit Ethernet
• Supports PoE and non-PoE devices
• Compatible with 2.5 GbE networks
• ESD and EMP protection
• Grounding point for safe surge discharge
• 90V DC spark-over voltage
• 700V maximum impulse spark-over voltage
• Low 1.0 pF capacitance
• IPX5 weatherproofing
• Compact installation-friendly design
• Polycarbonate enclosure
• Suitable for outdoor network installations
• Supports IEEE 802.3af PoE

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Overview

The Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 is designed to provide an additional layer of protection for Ethernet networking equipment against electrostatic discharge and electrical surges. It can be installed between an Ethernet device and the network connection to help protect equipment from transient electrical events.

The ETH-SP-G2 features two passive surge-protected RJ45 connections and supports both PoE and non-PoE Ethernet devices. Its grounding point allows surge energy to be safely discharged into a suitable grounded structure. The current Ubiquiti specifications also list compatibility with networks up to 2.5 Gbps and a 10kA+ discharge current.

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Price Table

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Key Specs

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Performance

• 10kA+ discharge capability provides substantial surge protection.
• Supports Ethernet connections up to 2.5 Gbps.
• Protects both PoE and non-PoE network equipment.
• Two RJ45 ports provide simple inline installation.
• Low capacitance helps minimize impact on Ethernet signal transmission.
• ESD and EMP protection helps protect sensitive network electronics.
• 90V DC spark-over voltage provides surge response.
• 700V maximum impulse spark-over voltage provides additional protection.
• Grounding capability allows transient energy to be discharged safely.
• Suitable for outdoor high-speed Ethernet installations.

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Smart Features

• Passive surge protection
• ESD protection
• EMP protection
• PoE protection
• Gigabit Ethernet support
• 2.5 GbE compatibility
• Grounding connection
• RJ45 inline connectivity
• Outdoor network protection
• Surge voltage absorption
• High discharge-current capability
• Simple installation
• Compatible with Ubiquiti outdoor networking equipment

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Design & Build

• Compact 91 × 61 × 32.5 mm enclosure
• Lightweight 80 g construction
• Polycarbonate housing
• IPX5 weatherproofing
• Two RJ45 Ethernet connections
• Dedicated grounding point
• Wall and pole mounting options
• Included grounding screw and serrated washer
• Designed for outdoor network installations
• Operating temperature from -30°C to 65°C

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Connectivity

• 2 × RJ45 female connectors
• Gigabit Ethernet support
• Up to 2.5 Gbps network compatibility
• PoE connectivity
• Non-PoE Ethernet connectivity
• Inline Ethernet installation
• Grounding connection
• Compatible with outdoor Ethernet devices
• Suitable for PoE access points and CPE equipment
• Suitable for wired network equipment

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Use Cases

• Outdoor WiFi installations
• PoE access point protection
• Wireless ISP deployments
• Ubiquiti airMAX installations
• Outdoor surveillance systems
• Ethernet cable protection
• Network equipment protection
• Pole-mounted network devices
• Building-to-building Ethernet links
• Business network installations
• High-speed outdoor Ethernet networks
• Lightning and surge protection installations

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Pros & Cons

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 FAQs

Q1: What does the ETH-SP-G2 protect against?

The ETH-SP-G2 provides protection against electrostatic discharge and transient electrical surges affecting Ethernet-connected equipment.

Q2: Does the ETH-SP-G2 support PoE?

Yes. It supports PoE and is designed to protect compatible PoE and non-PoE Ethernet devices.

Q3: What network speeds does the ETH-SP-G2 support?

Ubiquiti currently lists the ETH-SP-G2 as compatible with network connections up to 2.5 Gbps.

Q4: Does the ETH-SP-G2 need to be grounded?

Yes. Proper grounding is essential for the surge protector to safely discharge surge energy. Ubiquiti provides a dedicated grounding point and installation options for connection to a grounded structure.

Q5: Can the ETH-SP-G2 be used outdoors?

Yes. Its IPX5 weatherproofing and wide operating temperature range make it suitable for outdoor Ethernet installations when correctly installed and grounded.

Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 Conclusion

The Ubiquiti ETH-SP-G2 Ethernet Surge Protector Gen 2 is a compact and effective protection accessory for Ethernet networks that require additional defense against electrical surges and ESD. With 10kA+ discharge capability two RJ45 connections PoE support 2.5 Gbps compatibility IPX5 weatherproofing and a dedicated grounding point, it is an excellent choice for protecting outdoor access points CPE devices cameras and other Ethernet equipment in Kenya.
