Fanvil i504W SIP Indoor Station

Key Features of Fanvil i504W SIP Indoor Station

• 7-inch IPS Color Capacitive Touchscreen

• Resolution – 1024 × 600 Pixels

• Wi-Fi – Dual-Band 2.4GHz & 5GHz

• Ethernet – 10/100 Mbps

• PoE – IEEE 802.3af

• Speaker – 2W Multimedia

• Alarm Inputs – 8

• Short-Circuit Output – 1

• Doorbell Input – 1

• RS-485 – 1 Reserved

• Video Decoding – H.264, H.265 Optional

• Video Resolution – Up to 1080p

• SIP – UDP/TCP/TLS

• Wall-Mount Installation

• ABS Housing

Overview of Fanvil i504W SIP Indoor Station

The Fanvil i504W SIP Indoor Station is a 7-inch touchscreen indoor communication and access-control device designed for residential communities, villas, hotels and offices. It supports SIP-based two-way communication, video monitoring, remote door unlocking and security sensor integration, with dual-band Wi-Fi and PoE providing flexible network connectivity.

Fanvil i504W SIP Indoor Station Price in Kenya

Specifications of Fanvil i504W SIP Indoor Station

Performance Features of Fanvil i504W SIP Indoor Station

• 7-Inch Touchscreen: The large 7-inch IPS capacitive touchscreen provides an intuitive interface for managing intercom calls, viewing visitors, monitoring connected cameras and accessing door-control functions. The 1024 × 600 resolution delivers clear visual information for everyday indoor access-control use.

• Full-Duplex Hands-Free Communication: The 2W multimedia speaker and Acoustic Echo Cancellation support clear two-way hands-free conversations between occupants and visitors without requiring a traditional handset.

• Video Monitoring: The i504W supports hardware video decoding and can display feeds from compatible door phones and third-party IP cameras, making it possible to monitor visitors and connected surveillance points from the indoor station.

• Remote Door Access: When integrated with a compatible door station and access-control system, users can remotely unlock the entrance directly from the indoor station.

Connectivity and Security Features of Fanvil i504W SIP Indoor Station

• Dual-Band Wi-Fi: Built-in 2.4GHz and 5GHz Wi-Fi provides flexible wireless network connectivity for installations where a wired network connection may not be convenient.

• PoE Connectivity: IEEE 802.3af Power over Ethernet enables compatible network infrastructure to provide both power and network connectivity through Ethernet, simplifying installation.

• Multiple Alarm Inputs: Eight alarm inputs provide extensive connectivity for security sensors and other monitoring devices, while the doorbell input and short-circuit output expand its access-control capabilities.

• SIP Communication: SIP 2.0 support over UDP, TCP and TLS allows the i504W to integrate with compatible SIP-based intercom and communication systems.

Installation and Integration Features of Fanvil i504W SIP Indoor Station

• Wall-Mounted Installation: The slim 177.38 × 113.99 × 22.5 mm enclosure is designed for wall-mounted deployment, making the station suitable for fixed indoor locations.

• Access-Control Integration: The combination of alarm inputs, doorbell input, short-circuit output and reserved RS-485 interface provides connectivity for broader building security and automation systems.

• Flexible Power Options: The device supports either 12V DC power or IEEE 802.3af PoE, allowing installation according to the available electrical and network infrastructure.

• Wide Video Compatibility: Support for H.264 and optional H.265 decoding, with resolutions up to 1080p, allows the indoor station to work with compatible video intercom and IP-camera systems.

Applications of Fanvil i504W SIP Indoor Station

• Residential apartments and gated communities

• Villas and private homes

• Hotels and hospitality facilities

• Office buildings

• Video intercom systems

• Visitor management

• Door access-control systems

• Building security installations

• IP camera monitoring

Pros and Cons of Fanvil i504W SIP Indoor Station

FAQs About Fanvil i504W SIP Indoor Station

What is the Fanvil i504W used for?

The Fanvil i504W is an indoor SIP video intercom and access-control station used in residential communities, villas, hotels and offices.

Does the Fanvil i504W have Wi-Fi?

Yes. The i504W supports dual-band 2.4GHz and 5GHz Wi-Fi.

Does the Fanvil i504W support PoE?

Yes. It supports IEEE 802.3af PoE as well as 12V DC, 1A external power.

Can the Fanvil i504W unlock doors?

Yes. The indoor station supports remote door unlocking when connected to a compatible access-control system.

What size screen does the Fanvil i504W have?

It has a 7-inch IPS color capacitive touchscreen with a 1024 × 600 pixel resolution.

Can the Fanvil i504W connect to IP cameras?

Yes. It supports viewing live video feeds from linked third-party IP cameras and compatible door phones.

Conclusion

The Fanvil i504W SIP Indoor Station combines a 7-inch touchscreen with SIP communication, dual-band Wi-Fi, PoE, video monitoring, remote door unlocking and multiple alarm interfaces. It is well suited for residential, hotel and office access-control installations requiring an integrated indoor communication and security terminal.
