Blackmagic Design ATEM Production Studio 4K Live Switcher

Blackmagic Design ATEM Production Studio 4K Live Switcher

• Supports 10-Bit NTSC/PAL/HD/UHD 4K
• Supports 4K Resolution over SDI or HDMI
• 4 x 6G-SDI & 4 x HDMI Inputs (4K/HD/SD)
• Tri-Sync/Blackburst Ref. Sync Input
• 8 x Built-In Frame Synchronizers
• Multiview Monitoring in HD
• Program Outputs in SD/HD/4K HD
• 1 x Upstream & 2 x Downstream Keyers
• Audio: 10 x Input, 2-Channel Mixer
• Hardware or Software Mac/Windows Control

Blackmagic Design ATEM Production Studio 4K Live Switcher

Blackmagic Design ATEM Production Studio 4K Live Switcher with Eight Ultra HD Inputs and Real-Time Live Switching

The Blackmagic ATEM Production Studio 4K Live Switcher is a versatile live event multicamera production switcher designed to handle up to eight Ultra HD inputs, all integrated into a 1 RU chassis. It supports NTSC, PAL, HD, and Ultra HD video formats via four Single-Link 6G-SDI and four 4K HDMI inputs, offering seamless connectivity with a variety of cameras and sources. This switcher enables live video production in SD, HD, or UHD 4K without requiring any rendering, ensuring smooth, real-time video creation.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Built-In Frame Synchronizers and Reference Video Input for Seamless Integration

Each input on the ATEM Production Studio 4K features its own frame synchronizer, allowing you to use cameras that do not have Genlock and to input video from computer sources. The switcher also has a reference video input for synchronizing with other equipment using tri-level or Blackburst Sync, ensuring all devices in your production workflow remain in perfect sync.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Six Always Active Video Outputs for Flexible Video Routing

The switcher provides six active video outputs, including one SDI and one HDMI program output, both supporting SD/HD/UHD 4K resolutions. It also includes one auxiliary SD/HD/UHD 4K output, delivering a clean program feed without any downstream effects, and an HD-only program output signal for monitoring on SDI-equipped HD monitors. With dedicated multiview outputs, users can view the program, preview, six active inputs, and two graphic channels (media players) on one screen at the same time.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Built-In Audio Mixer for Easy Audio Integration

The ATEM Production Studio 4K includes a built-in two-channel audio mixer, which handles audio from the embedded HDMI and SDI video inputs, as well as audio from the balanced and unbalanced analog audio inputs. This audio mixer gives you the flexibility to control both the video and audio for a fully integrated live production.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Multi-Format Inputs for Diverse Production Needs

The ATEM Production Studio 4K is capable of handling all inputs simultaneously, thanks to its eight available video inputs. It supports four single-link 6G-SDI and four HDMI 4K inputs, allowing you to connect a variety of video sources, including SD, HD, Ultra HD, and computer-based signals. The switcher ensures that all inputs can be used at once without compromising performance.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Customizable Multiview Monitoring for Enhanced Production Control

The switcher’s multiview monitoring allows you to see the program, preview, six active video inputs, and two graphic channels on a single screen, which is ideal for managing complex live production workflows. You can also add custom labels to identify each input clearly, enhancing the ease of switching between camera angles and sources during live events.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Advanced Effects and Keyers for Real-Time Graphics and Composites

The ATEM Production Studio 4K is equipped with an upstream keyer and two downstream keyers for adding real-time effects, graphics, and composites in Ultra HD resolution. The keyers support chroma, pattern, shape, and luma keying with 10-bit processing, enabling you to add polished graphics like lower thirds, titles, logos, and more to your live broadcast.

Blackmagic Design ATEM Production Studio 4K Live Switcher with Ethernet Control for Seamless Operation

Control the ATEM Production Studio 4K via Ethernet, either through the included ATEM Software Control on a Mac or Windows computer or with an optional ATEM Broadcast Panel. This gives you full control over all production settings, as well as the ability to directly import graphics from your computer’s media pool. The switcher’s Ethernet connection also allows for remote control, providing flexibility for large-scale or distributed productions.

Blackmagic Design ATEM Production Studio 4K Live Switcher with USB and Mini-USB Ports for Software Updates and Configuration

The switcher features a mini-USB port for software updates and to configure the chassis' IP address. Using the ATEM Switcher Utility, you can connect a computer to this port to make any necessary updates or adjustments.

Blackmagic Design ATEM Production Studio 4K Live Switcher with 1 RU Rack Mount Design for Space-Saving Integration

The ATEM Production Studio 4K is designed for easy integration into production environments with its 1 RU height and built-in rack mount ears. It’s perfect for mounting in road cases or post-production facilities, providing both portability and versatility for live events and broadcast environments.
